Multi language DS 2DC2402IW D3 H 265 4MP MINI PTZ IP onvif Dome Camera IR SD

Multi-language DS-2DC2402IW-D3 H.265 4MP MINI PTZ IP onvif Dome Camera IR SD Card Slot 2X Zoom Built In Mic Audio 3D Positioning

100 % of buyers enjoyed this product!
Availability: in stock
Price:  US $168.00 / piece
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days


USD 350.00/pieceUSD 74.95/pieceUSD 364.00/pieceUSD 93.00-108.00/pieceUSD 91.50/pieceUSD 74.50/pieceUSD 144.90-156.00/piece Original Multi-language DS-2DC2402IW-D3 H.265 4MP MINI PTZ IP onvif Dome Camera IR SD Card Slot 2X Zoom Built In Mic Audio 3D Positioning

Key Features:

Basic function

High performance CMOS, up to 4MP (2560 x 1440)@25/30fps resolution

H.265/H.264/MJPEG video compression

Power-off memory function: restore PTZ & Lens status after reboot

Built-in microphone

Support Hik cloud P2P

Event Functions

Detections: intrusion detection, line crossing detection, motion detection

Support low bit rate, ROI

Camera function

3mm – 6mm, 2X optical zoom

Auto iris, auto focus, auto white balance, backlight compensation and auto day & night switch

Min. Illumination: [email protected](F2.0,AGC ON)(Color), [email protected](F2.0,AGC ON)(B/W)

Support privacy masks

PTZ functions

0-350° pan range and 0°-90° tilt range

0.1°-60°/s Manual Pan Speed and 0.1°-50°/s Manual Tilt Speed

Presets Speed 50°/s

300 presets programmable

Support 8 cruise scan, 32 presets per cruise

3D intelligent positioning function

Network function

Micro SD card slot, up to 128GB

Support up to NAS storage

1 Audio input and 1 Audio output

1 Alarm input and 1 Alarm output

Built-in microphone

Technical parameters:



Image Sensor

1/3″ Progressive Scan CMOS

Max.Image Resolution

2560 (H) x 1440 (V)

Signal System


Minimum Illumination

F2.0, AGC On : Color : 0.05 lux, B/W : 0.01 lux

White Balance

Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp









Shutter Time


Day& Night


Digital Zoom


Privacy Masking

8 privacy masks programmable

Auto Focu

Auto / Semi-automatic / Manual


Focal Length

3~6mm, 2x

Zoom Speed


Angle of View

100-45 degree

Aperture Range


Pan & Tilt

Pan Range

Pan: 0~350°

Pan Speed

Pan Manual Speed: 0.1°~60°/s

Tilt Range

Tilt: 0°~90°

Tilt Speed

Tilt Manual Speed: 0.1°~50°/s

Number of Preset


Power Off Memory


Watch Function

preset point

Park Action


PTZ Position Display


Infrared function

Infrared Distance

30 meters

Smart IR



Alarm Input


Alarm Output


Alarm Actions

Preset, Recording, Relay output, Upload center, Upload FTP, Email linkage

Input & Output

Audio Input

1 built-in microphone; 1 audio input (Mic/Line in), 2~2.4V[p-p];

output impedance: 1KΩ, ±10%

Audio Output

1 Audio output interface

Line level, impedance: 600Ω



10Base -T, /100Base-TX, RJ45 Connector

Max.Image Resolution

2560 x 1440

Main Stream

50Hz:25fps(2560 x1440,2048 x 1536,1920 x 1080,1280 x 960,1280 x 720)

60Hz:30fps(2560 x 1440,2048 x 1536,1920 x 1080,1280 x 960,1280 x 720)

Sub Stream

50Hz:25fps(704 x 576),25fps(352 x 288),25fps(320 x 240)

60Hz:30fps(704 x 480),30fps(352 x 240),30fps(320 x 240)

Image Compression


Audio Compression





No. of Simultaneous Users

Up to 20 users

Dual Stream


Mini SD Card

Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording

User/Host Level

Up to 32 users,3 Levels: Administrator, Operator and User

Security Measures

User authentication (ID and PW),

Host authentication (MAC address)

IP address filtering



Client GUI

Date & Time Display

Time: Week: Date, 6 formats on the Client


Support iVMS-4200

Web Browser

IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +


Power Supply

12VDC , PoE(no support)

Power Consumption


Working Temperature/Humidity

-10degree -5010degree (indoor dome)

Protection Level

IP54, TVS 4000V lightning protection, surge protection and

voltage transient protection


Various mounting modes optional


Φ125 x 137.2mm

Weight (approx.)


iVMS-4200 Client Software
